Activated carbon has been historically used for removal of odor, removal of color pigments from water. Further, our expertise lies in making available both Domestic and Industrial models of Activated Caron Filter, it also used as per treatment system in RO plant (ROP) and post treatment system in Waste water treatment plants (STP & ETP).

Activated Carbon filters offered by us are used for eliminating bad taste, odor as well as chlorine residue in water. This excellent filter media has carbon granules of high iodine value that helps contaminants to get adsorbed to surfaces of carbon particles

PROCESS DESCRIPTION :-

The water passes through the Activated carbon filter, the filter media consist of activated granular carbon. Activated carbon adsorbs onto its surface free chlorine, organic compounds, colour and odour. The activated carbon bed is supported by a multilayer graved bed. The activated carbon bed is also backwashed at fixed intervals to dislodge any accumulated dirt particles.

BACK WASH :-

As the filtration progress the filter media gets loaded with the retained particles, this results in a continuous increase of pressure drop across the filter, when a predetermined pressure drop level is achieved the filter is shut down for cleaning. The filter media is cleaned by backwash system. After backwashing the filter is rinsed with raw water and after the required quality of water is achieved the filter is put back into service. Depending on the filtered water quality required backwashing is either done with raw water or with filtered water.

PRODUCT MODEL AVAILABILITY :-

Activated Carbon filter plants are comprises of Mild Steel /SS / FRP Pressure Vessel, Frontal piping wok with manual / Automatic multi port valve butterfly valve / conventional valves for easy operation and control. Available from 1,000 Liters/hr. to 1,00,0000 Liters/hr.
